MBR0530T1G

MBR0530T1G
型号:MBR0530T1G
品牌:ON ON
批号:13+
封装:SOD-123
原价:0.37
数量:568476
PDF电子文档:
订购电话:86755-83294757
要查看会员价请注册登陆
备注:Original in stock 原装现货
更多

  • 搜索此图
  • 收藏商品
  • 加入购物车
详细描述

 MBR0530T1G

Surface Mount Schottky Power Rectifier Plastic SOD−123 Package


The MBR0530T1/3 uses the Schottky Barrier principle with a large
area metal−to−silicon power diode. Ideally suited for low voltage,
high frequency rectification or as free wheeling and polarity
protection diodes in surface mount applications where compact size
and weight are critical to the system. This package also provides an
easy to work with alternative to leadless 34 package style. These
state−of−the−art devices have the following features:
Features
• Guardring for Stress Protection
• Low Forward Voltage
• 125°C Operating Junction Temperature
• Epoxy Meets UL 94, V−0 @ 0.125 in
• Package Designed for Optimal Automated Board Assembly
• Pb−Free Packages are Available
Mechanical Characteristics
• Reel Options: MBR0530T1 = 3,000 per 7 in reel/8 mm tape
Reel Options: MBR0530T3 = 10,000 per 13 in reel/8 mm tape
• Polarity Designator: Cathode Band
• Weight: 11.7 mg (approximately)
• Case: Epoxy, Molded
• Finish: All External Surfaces Corrosion Resistant and Terminal
Leads are Readily Solderable
• Lead and Mounting Surface Temperature for Soldering Purposes:
260°C Max. for 10 Seconds
