RDA5807M

由于客户采购批量与样品的价格不同，网上无法统一注明，请您把采购型号通过邮件或客服QQ401799895发给我们，也可以拨打明佳达国内销售部电话：0755-83957301，由客服人员为您报价；有时元件厂商价格稍许变动，本公司未能及时调整，如您觉得售价稍高，请与我们说明并适当议价；感谢支持.

RDA5807M  -  SINGLE-CHIP BROADCAST FM RADIO TUNER

Features

 CMOS single-chip fully-integrated FM tuner

 Low power consumption

 Total current consumption lower than 20mA at 3.0V

power supply when under normal situation

 Support worldwide frequency band

 50 -115 MHz

 Support flexible channel spacing mode

 100KHz, 200KHz, 50KHz and 25KHz

 Support RDS/RBDS

 Digital low-IF tuner

 Image-reject down-converter

 High performance A/D converter

 IF selectivity performed internally

 Fully integrated digital frequency synthesizer

 Fully integrated on-chip RF and IF VCO

 Fully integrated on-chip loop filter

 Autonomous search tuning

 Support 32.768KHz crystal oscillator

 Digital auto gain control (AGC)

 Digital adaptive noise cancellation

Mono/stereo switch

 Soft mute

 High cut

 Programmable de-emphasis (50/75 s)

 Receive signal strength indicator (RSSI) and SNR

 Bass boost

 Volume control and mute

 Line-level analog output voltage

 32.768 KHz 12M,24M,13M,26M,19.2M,38.4MHz

Reference clock

 Only support 2-wire bus interface

 Directly support 32Ω resistance loading

 Integrated LDO regulator

 1.8 to 3.3 V operation voltage

 MSOP－10pins

1.2 Applications

 Cellular handsets

 MP3, MP4 players

 Portable radios

Because of wholesale price is different from sample price, our website cannot state. Please contact us online. As well as welcome you call us : 0755-83957301.We will offer a right price; Sometimes manufacturer's price is unstable, so we don't adjust price
