VIC068A-GMB

VIC068A-GMB
型号:VIC068A-GMB
品牌:CYPRESS CYPRESS
批号:13+RoHs
封装:PGA
原价:100
数量:550250
PDF电子文档:
订购电话:86755-83294757
要查看会员价请注册登陆
备注:100% 全新原装 (New and original)
更多

  • 搜索此图
  • 收藏商品
  • 加入购物车
详细描述

VIC068A-GMB

VMEbus Interface Controller



Features
Complete VMEbus interface controller and arbiter
58 internal registers provide configuration control
and status of VMEbus and local operations
Drives arbitration, interrupt, address modifier utility,
strobe, address lines A07 through A01 and data lines
D07 through D00 directly, and provides signals for
control logic to drive remaining address and data
lines
Direct connection to 68xxx family and mappable to
non-68xxx processors
Complete master/slave capability
Supports read, write, write posting, and block transfers
Accommodates VMEbus timing requirements with
internal digital delay line (1⁄ 2-clock granularity)
Programmable metastability delay
Programmable data acquisition delays
Provides timeout timers for local bus and VMEbus
transactions
Interleaved block transfers over VMEbus
Acts as DMA master on local bus
Programmable burst count, transfer length, and interleaved period interval
 Supports local module-based DMA
Arbitration support
Supports single-level, priority and round robin arbitration
Supports fair request option as requester
Interrupt support
Complete support for the VMEbus interrupts: interrupter and interrupt handler
Seven local interrupt lines
8-level interrupt priority encode
Total of 29 interrupts mapped through the VIC068A
Miscellaneous features
Refresh option for local DRAM
Four broadcast location monitors
Four module-specific location monitors
Eight interprocessor communications registers
PGA or QFP packages
Compatible with IEEE Specification 1014, Rev. C
Supports RMC operations
See the VMEbus Interface Handbook for more information


Because of wholesale price is different from sample price, our website can not state.Please send your required part number via email to Sales@hkmjd.com or add our skype id mjdccm898 for online talking.As well as welcome you call us : 0755-83957301  We will send offer for you;  Sometimes manufacturer's price is unstable, so we don't adjust price in time. if you feel price is a little high for you, just feel free to contact us for consultation. Thank you for your support !


批发与零售价位不同,无法一一明示,详情请通过邮件或客服咨询(国内销售部电话:0755-83957301,企业QQ2850151585), 由于电子元器件价格不稳定,时常有稍许变动,本公司未能及时调整,如您觉得售价不适,请与我们说明并适当议价,谢谢支持。

与VIC068A-GMB相关的产品
与VIC068A-GMB相关的型号
型号 品牌 批号 封装 数量 备注 资料
 VIC068A-GMB  CYPRESS  13+RoHs  PGA  550250  100% 全新原装 (New and original)
 VIC068A-BC  Cypress  13+RoHs  PGA  78005  100% 全新原装 (New and original)
