ATTINY84A ATTINY84A-SSU ATTINY84A-SSUR -- 8-bit Microcontroller with 2K/4K/8K Bytes In-System Programmable Flash
Features
• High Performance, Low Power AVR® 8-bit Microcontroller
• Advanced RISC Architecture
– 120 Powerful Instructions – Most Single Clock Cycle Execution
– 32 x 8 General Purpose Working Registers
– Fully Static Operation
• High Endurance, Non-volatile Memory Segments
– 2K/4K/8K Bytes of In-System, Self-programmable Flash Program Memory
• Endurance: 10,000 Write/Erase Cycles
– 128/256/512 Bytes of In-System Programmable EEPROM
• Endurance: 100,000 Write/Erase Cycles
– 128/256/512 Bytes of Internal SRAM
– Data Retention: 20 years at 85°C / 100 years at 25°C
– Programming Lock for Self-programming Flash & EEPROM Data Security
• Peripheral Features
– One 8-bit and One 16-bit Timer/Counter with Two PWM Channels, Each
– 10-bit ADC
• 8 Single-ended Channels
• 12 Differential ADC Channel Pairs with Programmable Gain (1x / 20x)
– Programmable Watchdog Timer with Separate On-chip Oscillator
– On-chip Analog Comparator
– Universal Serial Interface
• Special Microcontroller Features
– debugWIRE On-chip Debug System
– In-System Programmable via SPI Port
– Internal and External Interrupt Sources
• Pin Change Interrupt on 12 Pins
– Low Power Idle, ADC Noise Reduction, Standby and Power-down Modes
– Enhanced Power-on Reset Circuit
– Programmable Brown-out Detection Circuit with Software Disable Function
– Internal Calibrated Oscillator
– On-chip Temperature Sensor
• I/O and Packages
– Available in 20-pin QFN/MLF/VQFN, 14-pin SOIC, 14-pin PDIP and 15-ball UFBGA
– Twelve Programmable I/O Lines
• Operating Voltage:
– 1.8 – 5.5V
• Speed Grade:
– 0 – 4 MHz @ 1.8 – 5.5V
– 0 – 10 MHz @ 2.7 – 5.5V
– 0 – 20 MHz @ 4.5 – 5.5V
• Industrial Temperature Range: -40°C to +85°C
• Low Power Consumption
– Active Mode:
• 210 µA at 1.8V and 1 MHz
– Idle Mode:
• 33 µA at 1.8V and 1 MHz
– Power-down Mode:
• 0.1 µA at 1.8V and 25°C
核心处理器 |
AVR |
核心尺寸 |
8-位 |
速度 |
20MHz |
连接性 |
USI |
外设 |
欠压检测/复位,POR,PWM,温度传感器,WDT |
I/O 数 |
12 |
程序存储容量 |
8KB(4K x 16) |
程序存储器类型 |
闪存 |
EEPROM 容量 |
512 x 8 |
RAM 容量 |
512 x 8 |
电压 - 电源 (Vcc/Vdd) |
1.8 V ~ 5.5 V |
数据转换器 |
A/D 8x10b |
振荡器类型 |
内部 |
工作温度 |
-40°C ~ 85°C |
封装/外壳 |
14-SOIC(0.154",3.90mm 宽) |
-------------------------------------------------------------------------------------------------------------------------
【買家必讀】:電子元器件是專業型的產品,技術含量較高,本身可能存在多種品牌,後輟與封裝,可能導致參數與性能的差異,如有不慎,很有可能導致元器件購買錯誤,為了更好的解決您的問題,所以請您務必在下单前,將產品的封裝、後綴告訴我們。以便我們能準確迅速的为您查询。
由于客户采购批量与样品的价格不同,网上无法统一注明,请您把采购型号通过页面旺旺或客服 QQ 401799895 或拨打国内销售部电话:0755-83957301,由客服人员为您报价;有时元件厂商价格稍许变动,本公司未能及时调整,如您觉得售价稍高,请与我们说明并适当议价,我们会根据市场情况给您相应的折扣,我们保证提供最市场最优势的价格最好元器件;感谢支持(所售元件均无含税,需开普票7%和增值票17%的客户请说明)
-------------------------------------------------------------------------------------------------------------------------
MJD is a corporation which engaged in agency electronic components. MJD Through seventeen years unrimitting efforts, aspire to provide our customers with world-leading products and service. Now already became a one of the most famous electronic components distributor in China.
Because of wholesale price is different from sample price, our website can not state.Please send your required part number via email to Sales@hkmjd.com or add our skype id mjdccm898 for online talking.As well as welcome you call us : 0755-83957301 We will send offer for you; Sometimes manufacturer's price is unstable, so we don't adjust price in time. if you feel price is a little high for you, just feel free to contact us for consultation. Thank you for your support !
