S-8261

S-8261
型号:S-8261
品牌:SEIKO SEIKO
批号:13+RoHs
封装:SOT23-6
原价:1.2
数量:78005
PDF电子文档:
订购电话:86755-83294757
要查看会员价请注册登陆
备注:100% 全新原装 (New and original)
更多

  • 搜索此图
  • 收藏商品
  • 加入购物车
详细描述

S-8261 - BATTERY PROTECTION IC FOR SINGLE-CELL PACK



Features
(1) Internal high accuracy voltage detection circuit
Overcharge detection voltage   3.9 V to 4.4 V (applicable in 5 mV step)
 Accuracy: ±25 mV (+25 °C) and ±30 mV (−5 °C to +55 °C)
Overcharge hysteresis voltage   0.0 V to 0.4 V
*1
  Accuracy: ±25 mV
The overcharge hysteresis voltage can be selected from the range 0.0 V to 0.4 V in 50 mV step.
Overdischarge detection voltage   2.0 V to 3.0 V (applicable in 10 mV step)  Accuracy: ±50 mV
Overdischarge hysteresis voltage   0.0 V to 0.7 V
*2
  Accuracy: ±50 mV
The overdischarge hysteresis voltage can be selected from the range 0.0 V to 0.7 V in 100 mV step.
Overcurrent 1 detection voltage   0.05 V to 0.3 V (applicable in 10 mV step)  Accuracy: ±15 mV
Overcurrent 2 detection voltage   0.5 V (fixed)  Accuracy: ±100 mV
(2) High voltage device is used for charger connection pins
(VM and CO pins: absolute maximum rating = 28 V)
(3) Delay times (overcharge: tCU, overdischarge: tDL, overcurrent 1: t
lOV1, overcurrent 2: t
lOV2) are generated
by an internal circuit.  No external capacitor is necessary. Accuracy: ±20%
(4) Three-step overcurrent detection circuit is included.
(overcurrent 1, overcurrent 2 and load short-circuiting)
(5) 0 V battery charge function “available” / “unavailable” are selectable.
(6) Charger detection function and abnormal charge current detection function
The overdischarge hysteresis is released by detecting negative voltage at the VM pin (−0.7 V typ.).
(Charger detection function)
When the output voltage of the DO pin is high and the voltage at the VM pin is equal to or lower than
the charger detection voltage (−0.7 V typ.), the output voltage of the CO pin goes low.  (Abnormal
charge current detection function)
(7) Low current consumption
Operation mode 3.5 µA typ., 7.0 µA max.
Power-down mode 0.1 µA max.
(8) Wide operating temperature range   −40 °C to +85 °C
(9) Small package  SOT-23-6, 6-Pin SNB(B)
*1. Overcharge release voltage = Overcharge detection voltage − Overcharge hysteresis voltage
(where overcharge release voltage < 3.8 V is prohibited.)
*2. Overdischarge release voltage = Overdischarge detection voltage + Overdischarge hysteresis voltage
(where overdischarge release voltage > 3.4 V is prohibited.)
